| CAT Crawler Excavator 349 | Unit | Value | |
| Key parameters | Net Power | kW | 302 |
| Operating Weight | Kg | 47500 | |
| Max.Digging depth | mm | 7700 | |
| Engine | Model | C13 | |
| Bore | mm | 130 | |
| Stoke | mm | 157 | |
| Hydraulic system | Max.flow | L /min | 779 |
| Max.Pressure-Equipment | Kpa | 35000 | |
| Max.Pressure- Travel | Kpa | 35000 | |
| Max.Pressure-Swing | Kpa | 26000 | |
| Swing Mechianism | Swing Speed | r/min | 8.44 |
| Max. Swing Torque | kN-m | 187 | |
| Dimensions | Boom | Reach 6.9m (22'8") | |
| Stick | R3.35m (11'0") | ||
| Bucket | SD 2.41 m³ (3.15 yd³) | ||
| Shipping Height - Top of Cab | mm | 3230 | |
| Handrail Height | mm | 3370 | |
| Shipping Length | mm | 11920 | |
| Transport Width | ft | 11 | |
| Service Refill Capacities | Fuel Tank Capacity | L | 715 |
| Cooling System | L | 52 | |
| Engine Oil | L | 40 | |
| Swing Drive - Each | L | 10.5 | |
| Final Drive - Each | L | 15 | |
| Hydraulic System - Including Tank | L | 550 | |
| Hydraulic Tank | L | 217 | |
