Sany Used Rotary Drilling Rig SR285R Model 2017 |
|||
|
Product Discription |
Unit | Parameter | |
| Pile | Max.Pile diameter | mm | 2000 |
| Max. Pile depth | m | 68/54 | |
| Rotary Drive | Rated output torque | KN-m | 225 |
| Rated Speed | rpm | 5~32 | |
| Crowd System | Crowd Force | KN | 210 |
| Line Pull | KN | 270 | |
| Stroke | mm | 5000 | |
| Main Winch | Lifting Capacity | KN | |
| Wire rope diameterr | mm | 32 | |
| Max. line speed | m/min | 70 | |
| Main Chassis | Base Engine | ISUZU 6WG1 | |
| Engine power | KW | 300 | |
| Emission Standard | Tier III | ||
| Overall | overall height | mm | 22870 |
| transport width*height*length | mm | 3540*3660*16385 | |
| Operating weight | kg | 81000 | |
