Sany Used Rotary Drilling Rig SR360H Model 2019 |
|||
| Product Discription | Unit | Parameter | |
| Pile | Max.Pile diameter | mm | 2500 |
| Max. Pile depth | m | 100/65 | |
| Rotary Drive | Rated output torque | KN-m | 360 |
| Rated Speed | rpm | 5~24 | |
| Crowd System | Crowd Force | KN | 290 |
| Line Pull | KN | 335 | |
| Stroke | mm | 6000 | |
| Main Winch | Lifting Capacity | KN | 360 |
| Wire rope diameterr | mm | 36 | |
| Max. line speed | m/min | 75 | |
| Main Chassis | Base Engine | ISUZU 6WG1 | |
| Engine power | KW | 300 | |
| Emission Standard | Tier III | ||
| Overall | Operating dimension Length | mm | 19910 |
| Operating dimension width | mm | 3530 | |
| Operating dimension height | mm | 3745 | |
| Operating weight | kg | 105000 | |
