Sany Used Truck Crane 25Tons 220KW Rpm Rated Power
| Sany STC250C4 Main Parameter | |||
| Part Descreption | Parameter | ||
| Capacity | Max. lifting capacity | 25 t | |
| Dimensions | Overall length/width/height | 12490/2500/3800mm | |
| Axle distance | 4225mm/1350mm | ||
| Gross weight | 30800kg | ||
| Power | Max. engine power | 220/2100kW/rpm | |
| Max. engine torque | 1250/(1200~1600) N·m/rpm | ||
| Traveling | Max.traveling speed | 85km/h | |
| Min.turning radius | 11m | ||
| Min.steering radius of boom tip | 12.5m | ||
| Min.ground clearance | 220mm | ||
| Max.gradeability | 41% | ||
| Fuel consumption per | 30L | ||
| Tail slewing radius of swingtable | 3.0m | ||
| Main Parameters | Boom section | 4 | |
| Boom shape | U shape | ||
| Base boom | 1078kN.m | ||
| Max.lifting moment | Full-extend boom | 659kN.m | |
| Full-extend boom+jib | 293kN.m | ||
| Base boom | 10.8m | ||
| Boom length | Full-extend boom | 35m | |
| Full-extend boom+jib | 43m | ||
| Outrigger span (Longitudinal×Transversal) | 5.28m×6.4m | ||
| Working speed | Max.single rope lifting main/auxiliary winch | (no load) | 125m/min |
| Full extension/retraction time of boom | 80s/95s | ||
| Full lifting/descending time of boom | 45s/50s | ||
| Slewing speed | (0～2.7)r/min | ||
