Sany Used Mobile Crane Trucks 220T 360KW Rpm Rated Power
| Sany SAC2200C 2019 Main Parameter | |||
| Part Descreption | Parameter | ||
| Capacity | Max. lifting capacity | t | 220 |
| Dimensions | Overall length/width/height | mm | 15815*3000*4000mm |
| Gross weight | kg | 54850 | |
| Power | Max. engine power | kW/rpm | 360 |
| Max. engine output tourque | N.m | 2200 | |
| Traveling | Max.traveling speed | km/h | 80 |
| Min.turning radius | m | 10 | |
| Approvach angle | ° | 20 | |
| Departure angle | ° | 17 | |
| Max.gradeability | % | 58 | |
Fuel consumption per hundred kilometers | L | 72 | |
| Main Parameters | Temperature range | – 20 ℃ ~ +40 ℃ | |
Min.rated range | m |
3 | |
Tail slewing radius of swingtable | m | 4.85 | |
Boom section | 6-U shape | ||
Full-extend boom | m | 3540 | |
Full-extend boom+jib | m | 952 | |
Outrigger span (Longitudinal×Transversal) | m | 8.5 × 8.3m | |
Jib offset | m | 0 °-40 ° | |
Working speed | Max speed, main hoist, single line,no load | m/min | 130 m/min |
Max speed, aux hoist, single line, no load | m/min | 130 m/min | |
Boom's full extending/Retracting time | s | 550/ 550 s | |
Boom's full raising/Lowering time | s | 60 / 90 s | |
| Swing speed | r/min | 1.5.0 r/min | |
