| Sany STC800 Main Parameter | |||
| Part Descreption | Parameter | ||
| Capacity | Max. lifting capacity | t | 80 |
| Dimensions | Overall length/width/height | mm | 15290*2800*3880 |
| Gross weight | kg | 50000 | |
| Power | Max. engine power | kW/rpm | 276/1900 |
| Max. engine output tourque | N.m/rpm |
1800/1000-1400
|
|
| Traveling | Max.traveling speed | km/h | 80 |
| Min.turning radius | m | 12 | |
| Approvach angle | ° |
≥10
|
|
| Departure angle | ° | ≥14 | |
| Max.gradeability | % | 41 | |
|
Fuel consumption per hundred kilometers
|
L |
≤44
|
|
| Main Parameters |
Max. rated lifting load
|
t | 80 |
|
Maximum turntable swing radius
|
m |
4.385
|
|
|
Minimum boom length
|
KN.m | 3293 | |
|
Maximum boom length
|
KN.m | 1803 | |
| Outrigger span (transverse x longitudinal) | m | 8*6.43m | |
| Minimum boom length | m | 12.96m | |
|
Maximum boom length
|
m | 50m | |
| Maximum boom length plus jib | m | 67.5m | |
|
Working speed |
Max speed, main hoist, single line,no load | m/min | 130 |
|
Max speed, aux hoist, single line, no load
|
m/min | 130 | |
|
Boom's full extending/Retracting time
|
s | 140/160 | |
|
Boom's full raising/Lowering time
|
s | 65/90 | |
| Swing speed | r/min | (0～1.8) | |
